EP1718J5

EP2720RD Red Mic.Cable.

DiMarzio® Microphone Cables with XLR ends connect mics to P.A.'s or any other balanced-line application. They deliver a natural sound with great dynamic range. Custom designed low-capacitance copper cable ensures low stage noise and maintains uniform capacitance throughout its length to guarantee consistent sound and improve high frequency response. Durable braided shielding lasts longer and produces much less "cable" noise. The woven nylon outer jackets are very durable and tangle less because they were designed to lay flat with minimum memory.

Secs:

Wire Gauge: AWG 22 x 2 (0.325 mm2).


Diameter: 0.295 in. (7.49 mm).

Insulation: Polyethylene inner with PVC outer.

Capacitance: 19 pF/ft (62 pF/M) cond/cond 35 pF/ft (115 pF/M) cond/shield.

Shield + Material: B.C. Braid 78% Coverage.

Jacket + Material: PVC + Nylon Overbraid.

Resistance: 5.5 ohm/1,000 ft (18 ohm/KM).

Inductance: 0.07 µH/ft (0.2 µH/M).

Termination Method: Silver Solder.
